IFM Electronic efector 190 Data Matrix Notice Pour Utilisateurs page 56

Selecting a configuration data file
Command master to sensor
Character Character/Meaning
position
1 p
2 tens digit of the sensor address
3 units digit of the sensor address
4 tens digit of the configuration data file number
5 units digit of the configuration data file number
6 command end
Response sensor to master
Character Character/Meaning
position
1 P
2 tens digit of the sensor address
3 units digit of the sensor address
4 tens digit of the configuration data file number
5 units digit of the configuration data file number
6 command end
7 command end
Example
master
p0305
transmits
sensor
responds
The trial to select a non existing configuration data file is ignored by the reader.
56
Comment
command character
digits 0-9
digits 0-9
digits 0-9
digits 0-9
(ASCII code 10 d )
Comment
command echo
digits 0-9
digits 0-9
digits 0-9
digits 0-9
(ASCII code 13
d
(ASCII code 10 d )
P0305
)
