Set basic parameters

This dialogue page is the first step to create a new configuration data file or to edit
an existing configuration data file.
Here you have to indicate if the code is in motion or stationary during the reading
process (more precise: during image capture).
Info
When you indicate that the code is in motion during the reading process, the image sensor of
the reader is programmed to a higher sensitivity. This means shorter exposure times and thus
a reduced "smearing effect" as the image is captured.
When all required parameters have been entered continue to the next step of the
parameter setting process via the
ton for the next dialogue page.
The execution of the current main task is indicated by a tick to be seen on the corre-
sponding button.
Button of the current
dialogue page
Button to the next
dialogue page
Next > button or via the
Explanations
(extended help)
Button to the next
dialogue page
Set image quality
but-
37
