entrematic Ditec ION4 Manuel Technique page 98

Type of
Display
alarm
EN
Description
V0 - Request for maintenance intervention Proceed with the scheduled maintenance
I5 - No voltage 0-1 (faulty voltage regulator
or short-circuit on accessories)
I6 - Excessive voltage 0-1 (faulty voltage
regulator)
I7 - Internal parameter error - value out-
side limits
I8 - Program sequence error
IA - Internal parameter error (EEPROM/
FLASH)
IB - Internal parameter error (RAM)
IC - Operation time-out error (>5 min or
>7 min in learning mode)
IE - Power supply circuit fault
IM - MOSFET alarm - motor in short cir-
cuit or always ON
IO - Interrupted motor power circuit (mo-
tor MOSFET open or always OFF)
IR - Motor relay error
IS - Error on motor current read circuit test Reset.
IU - Error on motor voltage read circuit
test
TH - Intervention of high temperature
safety device
VH - Automation blocked due to high
temperature
XX - Firmware reset commanded by the simultaneous pressing of the
keys.
+
WD - Firmware reset not commanded
intervention.
Check there is no short circuit in connec-
tion 0-1.
If the problem persists, replace the control
panel.
Replace the control panel.
Reset.
If the problem persists, replace the con-
trol panel.
Reset.
If the problem persists, replace the con-
trol panel.
Reset.
If the problem persists, replace the con-
trol panel.
Reset.
If the problem persists, replace the con-
trol panel.
Manually check that the gate moves free-
ly.
If the problem persists, replace the con-
trol panel.
Reset.
If the problem persists, replace the control
panel.
Reset.
If the problem persists, replace the con-
trol panel.
Check the settings / operating of any limit
switches.
Reset.
If the problem persists, replace the con-
trol panel.
Reset.
If the problem persists, replace the con-
trol panel.
If the problem persists, replace the control
panel.
Reset.
If the problem persists, replace the control
panel.
Do not carry out any operations.
If the problem persists, contact Technical
Service.
Do not carry out any operations.
If the problem persists, contact Technical
Service.
44
Operation
