Installation of the +CLIQ electronic locking cylinder

Length of the cylinder fixing screw

A cylinder fixing screw with a length of 85 mm is suitable for locks with a
backset of up to 75 mm. The following applies for locks with a larger
backset:
Length of the cylinder fixing screw = backset + 10 mm.
Assembling the profile c ylinder
Prerequisites: The mortise lock must be completely assembled.
Always observe the illustrated assembly instructions („Figures", page 74).
The locking cam position for profile cylinders can be changed if required
(„Changing the position of the locking cam", page 75).
1 Position the profile cylinder in the profile cylinder cut-out.
2 Secure the profile cylinder with the cylinder fixing screw.
The cylinder fixing screw supplied is suitable for locks with a backset
of up to 50 mm. The following applies for locks with a larger backset:
Length of the cylinder fixing screw = backset + 10 mm.
3 Only tighten the cylinder fixing screw by hand.
4 Check the locking cylinder for proper functionality and ease of
movement. To do this, actuate the locking cylinder several times with
the appropriate key.
 You have assembled the profile cylinder.
32 EN Assembly
