16 Communication Port

16.1

RS232 Interface

Description of DB-9 connector.

16.2 AS400 Interface (Option)

4
The E UPS may be equipped with an AS400 card (optional) for AS400 communication protocol. Please
contact your local distributor for details. The following is the pin assignment and description of DB-9
connector in AS400 card.
Description
Pin #
1 UPS Fail
Summary
2
Alarm
3 GND
Remote
4
Shutdown
5 Common
6 Bypass
7 Battery Low
8 UPS on
9 Line Loss
Note: It is also possible to insert a SNMP AGENT in the "Intelligent Slot".
INFOSEC UPS SYSTEM - 4, rue de la Rigotière – 44700 Orvault – FRANCE - www.infosec.fr
Hot Line :
Pin # Description
2 TXD
3 RXD
5 GND
I/O
Output
Output
Input
Input
Input
Output
Output
Output
Output
tel : + 33 (0)2 40 76 15 82 - fax : + 33 (0)2 40 94 29 51 - hotline@infosec.fr - 07 05 04 205 04
I/O
Output
Input
Input
Fig 16.2: DB-9 Interface of AS400
Communication protocol
