DIMENSIONI DI INGOMBRO, PESI, SPAZI DI
RISPETTO E COLLEGAMENTI IDRAULICI
AUSSENMAßE, GEWICHTE, RAUMBEDARF
UND HYDRAULISCHE ANSCHLÜßE
1850
140
510
1847
PART. ViSTA DA SOTTO
PART. VISTA DA SOTTO
PARTiCuLAR: ViEW FROM THE BOTTOM
DETAiL: ANSiCHT VON uNTEN
PARTiCuLiER: VuE Du FOND
Peso in funzione / Operating weight
Betriebsgewicht / Poids en fonction
MOD.
71
81
91
101
131
24
50
1290
23
(kg)
203
213
223
238
268
DIMENSIONS, WEIGHTS, CLEARANCES
AND HYDRAULIC CONNECTIONS
ENCOMBREMENTS, POIDS, ESPACES
POUR ENTRETIEN ET RACCORDEMENTS
HYDRAULIQUES
1000
ENTRATA ACQUA
WATER INLET
WASSEREINTRITT
ENTREE EAU
500
Entrata acqua / Water inlet
Wassereintritt / Entrée eau
Ø
1" M
1" M
1" M
1" M
1" M
1850
ENTRATA LINEA ELETTRICA
VOLTAGE SUPPLY INLET
99
ELEKTRISCHER ANSCHLUSS
ENTREE ALIMENTATION ELETRIQUE
USCITA ACQUA
WATER OUTLET
WASSERAUSTRITT
SORTIE EAU
RUBINETTO DI SCARICO
RUBINETTO DI CARICO
265
DRAINING VALVE
360
CHARGE SHUT OFF VALVE
1"M
ENTLEERUNGSHAHN
DRUCKVENTIL
SOUPAPE DE DECHARGE
ROBINET DE CHARGE
800
Uscita acqua / Water outlet
Wasseraustritt / Sortie eau
Ø
1" M
1" M
1" M
1" M
1" M
1"M
