Technical data
Name
610 ERGOLUX ® (2.0) - 13 cm
610 ERGOLUX ® (2.0) - 14 cm
610 ERGOLUX ® (2.0) - 15 cm
610 ERGOLUX (2.0) - 16 cm
®
610 ERGOLUX active (2.0) - 13 cm
®
610 ERGOLUX active (2.0) - 14 cm
®
610 ERGOLUX active (2.0) - 15 cm
®
610 ERGOLUX active (2.0) - 16 cm
®
602 ERGOLUX active (2.0) - 14 cm
®
602 ERGOLUX active (2.0) - 15 cm
®
602 ERGOLUX active (2.0) - 16 cm
®
602 ERGOLUX active (2.0) - 17 cm
®
601 ERGOLUX - 14 cm
®
601 ERGOLUX - 15 cm
®
601 ERGOLUX - 16 cm
®
601 ERGOLUX - 17 cm
®
621 ERGOLUX active (2.0) - 18 cm
®
621 ERGOLUX active (2.0) - 21 cm
®
621 ERGOLUX active (2.0) - 24 cm
®

Inspection and maintenance

Carefully check the surface of the saddle and the seat stays for possible damage regularly, at least twice a year, after 2000 km at the
latest and especially after crashes or other situations that exert unusually high force.
Warning
Damage may be difficult to detect. A cracking or creaking noise, as well as discoloration, cracks, and waves in the surface of the seat
stays may indicate damage due to overloading.
• If in doubt, do not continue cycling and consult your SQlab dealer without delay.
Art.no. Struts saddle
material struts-
diame-
2042 / (2232) CroMo Ø 7 mm
2043 / (2233) CroMo Ø 7 mm
2044 / (2234) CroMo Ø 7 mm
2045 / (2235) CroMo Ø 7 mm
1940 / (2228) CroMo Ø 7 mm
1941 / (2229) CroMo Ø 7 mm
1942 / (2230) CroMo Ø 7 mm
1943 / (2231) CroMo Ø 7 mm
1944 / (2427) CroMo Ø 7 mm
1945 / (2428) CroMo Ø 7 mm
1946 / (2429) CroMo Ø 7 mm
1947 / (2430) CroMo Ø 7 mm
2364 Ø 7 mm
BlackSteel
2365 Ø 7 mm
BlackSteel
2366 Ø 7 mm
BlackSteel
2367 Ø 7 mm
BlackSteel
2039 / (2431) CroMo Ø 7 mm
2040 / (2432) CroMo Ø 7 mm
2041 / (2433) CroMo Ø 7 mm
Weight max.
Saddle rider
weight
(g)
ter
245 100 kg
254 100 kg
259 100 kg
266 100 kg
275 100 kg
284 100 kg
286 100 kg
293 100 kg
460 130 kg
469 130 kg
476 130 kg
485 130 kg
335 130 kg
340 130 kg
355 130 kg
360 130 kg
625 130 kg
650 130 kg
674 130 kg
Max. Usage
tigh- range accor-
tening ding to ASTM
torque DIN EN
18 Nm Cat. 3
18 Nm Cat. 3
18 Nm Cat. 3
18 Nm Cat. 3
18 Nm Cat. 3
18 Nm Cat. 3
18 Nm Cat. 3
18 Nm Cat. 3
18 Nm Cat. 2
18 Nm Cat. 2
18 Nm Cat. 2
18 Nm Cat. 2
18 Nm Cat. 1
18 Nm Cat. 1
18 Nm Cat. 1
18 Nm Cat. 1
18 Nm Cat. 1
18 Nm Cat. 1
18 Nm Cat. 1
