Section 4
REMOVE PARTS FOR CLEANING
!
Disconnect electric power to the ice machine at the
electric switch box before proceeding.
A. Remove the Ice Thickness and Harvest Float
Switch
•
Pull forward on the bottom of the bracket until clear of
the tab, then slide bracket upward to remove the
bracket and float switch as an assembly.
NOTE: At this point, the float switch can easily be
cleaned. If complete removal is desired follow the wires
to the bulkhead grommet (exit point) in the back wall.
Pull the wire connector through the bulkhead grommet,
then disconnect the wire leads from the connector.
Part Number 040002909 5/13
Warning
WIRE CONNECTORS ARE LOCATED BEHIND BULKHEAD - PULL
THROUGH GROMMET TO DISCONNECT
ICE THICKNESSFLOAT
SWITCH & BRACKET
HARVEST FLOAT SWITCH & BRACKET
DISCONNECT WIRES
FOR COMPLETE
REMOVAL
Harvest or Ice Thickness Float Switch Removal
Maintenance
17
