b) The encryption can also be activated using the software "Device Monitor". This software can be ordered
separately as an option.
The encryption can only be deactivated using the software "Device Monitor".
1.3.2 LoRaWAN interface
The LoRaWAN interface transmits meter data (absolute values).
1.3.2.1 Technical data
Radio characteristics
Frequency 868 MHz
Output power 14 dBm
Receiver sensitivity -135 dBm
LoRaWAN characteristics
Device class
LoRa version
Activation
Data rate
*OTAA = Over-the-air activation
** ABP = Activation by personalization
1.3.2.2 LoRa module configuration
The module can be configurated by using the Device Monitors or the OTC App.
Parameter
Power mode
Configuration Lock
Synchronize meter time
Activation type
EcoMode
Transmit interval *[Min.]
Message format**
Pulse input selection
* The actual transmission interval depends on the type of telegram and the current data rate. The transmission
interval is adjusted accordingly in order to guarantee the set battery life (Eco Mode 10 or 6 years). You can find
more information in the „Manual LoRa Module".
** For pulse input option, the telegram type „Engelmann" must be selected.
Article no.:
Page 43 of 73
Frequency 868 MHz
Output power 14 dBm
Receiver sensitivity -135 dBm
Class A, Bi-directional
1.0.2 Rev B
OTAA* or ABP*
DR0-DR5 (250 bit/s-5470 bit/s)
Possible settings
Active
Inactive
Open
Locked
on
off
OTAA
ABP
off
6 years
10 years
5 ... 1440
Standard
Engelmann
Compact
JSON
Scheduled - daily redundant
Scheduled - extended
Combined heat/cooling
Choice between 0-3 pulse inputs
1080620016 Stand: 2022_01_04
Factory setting
Inactive
Open
off
OTAA
EcoMode 10 years
60
Standard
0
