I N S T A L L A T I O N I N S T R U C T I O N S F L U S H W A L L A N D C E I L I N G I N S T A L L A T I O N
Please inspect the power supply cord to the heater and the
surface before installation. These must not show any signs of
damage.
1. Unpack the device and accessories and check that they are
complete and undamaged. Please place the infrared heating
device only on clean, level surfaces so that no dirt can get into
the panel surface or the surface can be damaged.
3. Please note that in order to secure the frame with screws,
mounting aids (e.g. an aluminium profile or squared lumber
firmly connected to the ceiling) must be mounted on all 4 sides
of the cut-out.
5. Make sure that the frame is flush with the ceiling or wall.
Check all sides with a spirit level.
7. Check again that the frame has not warped during installa-
tion and is installed at a right angle.
For wall mounting, pay attention to the direction arrows on the
®
back of the LAVA before installation.
2. Remove the panel from the mounting frame. Only use the
enclosed lifting tool.
4. Insert the mounting frame into the cut-out. The click lock
must point forward.
6. Next, fix the frame to the mounting aid with the screws in the
holes provided for this purpose.
