3) If the image reproduction is not clear with correctly ad-
justed distance, the mechanical focus setting for the lens
must be adjusted. For this loosen the hexagonal screw
above next to the lens thread ring. Adjust a clear picture by
turning the lens thread ring. Then tighten the hex screw
again.
8 Specifications
Image sensor: . . . . . . . . . .
Synchronization: . . . . . . . . hor. 15 625 Hz, vertical 50 Hz
Number of pixels: . . . . . . . hor. 500 x vertical 582
Resolution: . . . . . . . . . . . . 380 TV lines
Min. illumination: . . . . . . . . 1 Lux/1 : 1.6
S/N ratio: . . . . . . . . . . . . . > 48 dB
Video output: . . . . . . . . . . . 1 Vpp/75 Ω and 1 Vpp/10 Ω for
Operating temperature: . . . -10°C up to +50°C
Power supply: . . . . . . . . . . 12 V , 120 mA, externally, e. g.
Dimensions (W x H x D)
without lens: . . . . . . . . . . . 60 x 75 x 110 mm
Weight (without lens): . . . . 225 g
According to the manufacturer.
Subject to technical change.
1
/ " CCD chip, 4.4 x 3.3 mm
3
the iris control
MONACOR PS-12CCD
GB
11
