Installation and Operating Specification EUR EC
9.6

Menu group Start

Main menu
Start up
Settings
Protocol
Base setup
Controller Setup
Start up
- - - - -
PIN input
Start up
D
Sprache
OFF
US Einheiten
Start up
OFF
Reset
Start up
1.01
Mode
L-BAL-E274-GB 1914 Index 003
Start up
PIN input
The service menu for the installation can be protected against unintentional changes
by a pin code. With further pin codes putting back to pre-setting is possible.
PIN 0010
Opening service menu, if PIN-protection activated.
PIN 1020
Reactivate wizard for first-time start-up
PIN 1234
Freischalten Menu group "Setting".
if "set protection" = "ON" (
PIN 9090
Restore user setting.
PIN 9091
Save user setting (corresponds function "Save user setup" = "ON"
PIN 9095
Restore factory setting = delivery status
Exception:
The stored events in the "Protocol" menu are retained after resetting to factory setting!
Language
In this menu different national languages can be selected (GB = English, D = German
...).
US Einheiten
The display can be switched between SI units and imperial (US) units =>US units ON.
SI units (factory setting): °C, bar, Pa, m
Imperial (US) units: °F , psi, in.wg, cfm, K-Faktor US, ft/s
Settings for temperature differences (with SI units in K) are also made for Imperial units
(US) in °F (Δ 1.8 °F Δ 1 K).
Conversion factors:
Temperature: t / °F = 1,8 x t °C + 32.
•
• Pressure: 1.0 psi = 0.069 bar, 1.0 in.wg = 254 Pa
Air flow: 1.0 cfm = 0.5885 m
•
Speed: 1.0 ft/s = 0.3048 m/s
•
In order to refresh the display, the desired mode must be confirmed again after switch-
ing over the units ( Base setup)!
Reset
Complete re-start of the device
Mode
Query of the operating mode (e.g.
Part.-No.
44/117
Controller Setup)
3
/h, K-Factor, m/s
3
/h, inlet ring: K-Factor US = 9.3 x K-Factor SI
1.01
for speed controller)
Programming
Controller Setup)
