Scheppach basato 3 Mode D'emploi page 16

Special Accessories
Cross cutting jig
Circular cutting device
Bit stop
Grinding belt device
Underframe for tables
Automatic starter, type ALV 2
Type ALV 10
Saw bands
for wood:
12/0.5/2360 mm, 4 teeth/inch
Standard saw band
15/0.5/2360 mm, 4 teeth/inch
Straight upright cuts with longitudinal stop
for wood and synthetic materials:
6/0.5/2360 mm, 6 teeth/inch
Turning works with small radius 25 mm
12/0.5/2360 mm, 6 teeth/inch
Precision cutting works
Different materials:
wood, synthetic materials, metals
3.5/0.5/2360 mm, 14 teeth/inch
Extra-fine cutting works, extremely small radiuses
Non-ferrous metals up to 10 mm
6/0.65/2360 mm, 22 teeth/inch
straight cuts and turning works
Synthetic materials, non-ferrous metals
6/0.65/2360 mm, 10 teeth/inch
Synthetic materials, non-ferrous metals above 15 mm
12/0.65/2360 mm, 10 teeth/inch
straight cuts and large radiuses > 60 mm
Failure
Saw blade gets loose after
turning off the motor
Motor does not start
Motor runs forward or
backwards
No motor output
turns off automatically
Burns on the cutting
surface
c) with longitudinal cuts
d) with cross cuts
GB12
7312 0025
}
7319 0710
7319 0709
7910 4010
7910 4020
7319 0701
7319 0704
7319 0702
7319 0705
7319 0706
73190707
73190703
73190708
Troubleshooting
Possible cause
a) Fastening nut tightened
insufficiently
a) Fastening nut tightened insufficiently a) Check the mains fuse.
b) Extension cable defect
c) Connections on the motor or
switch defect
d) Motor or switch defect
Capacitor defect
Overload by dull saw
blade, thermoprotection is triggered
a) Fastening nut tightened insufficiently a) Insert a sharpened saw blade
b) Wrong saw blade
longitudinal cuts
c) Longitudinal stop not parallel
d) Slide carriage not parallel
Solution
a) Tighten fastening nut, M20 left-handed thread
b) See "Electrical Connection" in the operating
manual, pages GB 11
c) Have it checked by an electrician
Brake does not bleed
d) See "Electrical Connection" in the operating
manual, pages GB 11
Have it exchanged by an electrician
Insert a sharpened saw blade; motor can be
turned on again
after the cooling period
b) Insert saw blade with 20 or 28 teeth for
c) Exchange the longitudinal stop
Align the slide carriage with the saw blade
