6.3

Changing the clamping jaw inserts

Turn the feeder hand wheel clockwise so that the tool carriage moves to the right end.
Bring the pipe cutter into an upright position so that it is not in the way.
Turn the clamping chuck and open it until a screwdriver fits inside.
Clamping chuck
Turn
Screw
Undo the screws that secure the clamping jaw inserts.
Release
Place a thin rod onto the upper edge of the spring and pull out the clamping chuck pin.
Spring
Clamping chuck pin
46
