4 Instructions on commissioning
You can set the field bus address of the SPC200 with the
WinPISA software package (as from version 4.1) or with
the control panel.
The SPC200 communicates with the master via an I/O field
(internal inputs/outputs). The permitted number of confi-
gurable inputs and outputs depends on the operating
mode of the SPC200 used (max. 8-byte inputs and 8-byte
outputs). This is summarized in the table below.
Operating Function of the inputs/outputs
mode
Start/Stop I10.0...I10.15
I11.0...I13.15
Q10.0...Q10.15
Q11.0...Q13.15
Record I10.0...I10.15
selection I11.0, I11.1 and
I11.8...I11.15
Q10.0...Q10.15
*) Address specification as seen by the SPC200
Festo SPC200-COM-CAN 0012NH English
For control signals and freely
programmable inputs
For freely programmable inputs
(optional)
For control signals and freely pro-
grammable outputs
Freely programmable outputs (op-
tional)
For control signals
For record number
For control signals
19
