SQUEEGEE ASSEMBLY GROUP - - 2701 Model / CONJUNTO PALETA - - Modelo 2701 / GROUPE DE LA
REF PART # DESCRIPTION
613953 ASM, SQUEEGEE, XR 2701
∇
611884 SQUEEGEE KIT, REPLMT
(RETROFIT) 965MM (38 IN)
(BEFORE SN 10030646)
609114 DKIT, SQUEEGEE BLADES,
∇
LINATEX & GUM RUBBER
965MM (38 IN)
1 222381 DBLADE, FRONT SQUEEGEE,
Y
LINATEX RED 965MM (38 IN)
2 609056 DBLADE, REAR SQUEEGEE GUM
Y
RUBBER TAN 965MM (38 IN)
609115 DKIT, SQUEEGEE BLADES,
∇
LINATEX 965MM (38 IN)
1 222381 DBLADE, FRONT SQUEEGEE,
Y Y
LINATEX RED 965MM (38 IN)
2 609055 DBLADE, REAR SQUEEGEE
Y Y
LINATEX RED 940MM (37 IN)
1 222391 DBLADE, FRONT SQUEEGEE
URETHANE WHITE 965MM (38 IN)
222385 DBLADE, FRONT SQUEEGEE
GUM RUBBER TAN 965MM (38 IN)
2 611713 DBLADE, REAR SQUEEGEE
URETHANE WHITE 965MM (38 IN)
609056 DBLADE, REAR SQUEEGEE GUM
RUBBER TAN 965MM (38 IN)
ASSEMBLY / CONJUNTO / ENSEMBLE
∇
INCLUDED IN ASSEMBLY / INCLUIDO A CONJUNTA / Y COMPRIS EN
Y
ENSEMBLE
RECOMMENDED STOCK ITEM / PIEZAS RECOMENDADAS EN ALMACÉN /
D
ELÉMENTS DE STOCK RECOMMANDÉS
* NOTE: TWO SQUEEGEE SPACERS ARE REQUIRED WITH REAR URETHANE
BLADE #611713 / SE REQUIEREN DOS SEPARADORES DE
ESCOBILLA CON LA HOJA DE URETANO #611713 / DEUX ENTRETOISES SONT
EXIGÉES AVEC LA LAME ARRIÈRE D'URÉTHANE #611713
Speed Scrub 2701/3301 (08- -05)
PARTS LIST - LISTA DE PIEZAS - LISTE DES PIÈCES
RACLETTE - - Modèle 2701
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
Home Find... Go To..
REF PART # DESCRIPTION
3 611661 CASTING, SQUEEGEE
Y
4 140799 SCREW, 5/16- -18X1- -1/2 TRSPHL
Y
5 140015 WASHER, 5/16 LOCK
Y
6 1011094
DKNOB
Y
7 130164 PLUG, DOME 3/8"
Y
8 1014918 DWHEEL, RUBBER, 3"X1"
Y
9 222505 SCREW, M8X1.25X45 HEXHD
Y
10 140027 WASHER, 5/16 FLAT
Y
11 08709 NUT, M8 HEXLCK
Y
12 222368 PLATE, BLADE RETAINER
Y
13 140055 WASHER, .343X1.25X.051- -.080
Y
14 222378 BAND WELDMENT, SQUEEGEE
Y
BLADE
15 609110 SPACER, SQUEEGEE *
Y
16 222794 DKNOB, 1/4- -20X1- -1/2
Y
17 82138 NUT, SPEED RETAINER .25- -20
Y
18 601108000 NUT, 5/16- -18 HEXLCK THIN
Y
19 611399 BRACKET, ROLLER, SQUEEGEE
Y
20 603144 SCREW, 5/16- -18 SHOULDER
Y
21 630477 DWHEEL, 2.00D X .38W
Y
22 603368 SPACER, .39X.75X.75 NYLON
Y
QTY.
1
2
2
6
2
2
2
4
2
1
4
1
1
2
2
1
1
1
2
1
