xFUME™ ADVANCED 115V – CSA
Tab. 1
Max. inlet air pressure
Weight
Dimensions (L × W × H)
1 One extraction hose connection length 5 m connected, second connection closed.
Tab. 2
Ambient temperature
(operation, storage in a closed
environment)
Ambient temperature (transport)
Relative humidity

5 Transport and installation

Risk of injury due to improper transport and installation
Improper transport and installation can cause the device to tip or fall over. This may result in serious
injuries.
► Check and wear your personal protective equipment.
► Ensure that the extraction hose is laid in a straight line.
► Ensure that all supply lines and cables do not encroach into the area in which employees are working.
► Place the device on a suitable base (flat, solid, dry) on which it will not topple over.
► Note the weight of the device when lifting it.
 4.3 Technical data on page EN-10
► Use an appropriate lifting tool with load handling attachment for transporting and installing the
device.
► Avoid abrupt lifting and setting down.
► Do not lift the device over persons or other devices.
NOTICE
Risk of material damage due to improper transport and installation
Improper transport or installation can cause the device to tip or fall over. This can result in material
damage and irreparable damage to the device.
► Protect the device against weather conditions, such as rain and direct sunlight.
► Ensure that the device does not make contact if you pass over edging.
► Use the device only in dry, clean and well-ventilated rooms.
► Maintain a minimum distance of 1 m from the wall when installing the device to ensure that the device
has sufficient ventilation.
 Abb. 2 Assembly and use on page EN-9
► Install the device and lock the castors (D).
General information
Ambient conditions for transport, storage and operation
WARNING
5 Transport and installation
xFUME™ ADVANCED 115V – CSA
6 bar
49 kg
370 mm × 370 mm × 990 mm
xFUME™ ADVANCED 115V – CSA
0 °C to +40 °C
-15 °C to +40 °C
Up to 90% at +20 °C
