Advanced applications
If you are using another sequencer
If you press the Sequencer control switch when the button is dark, the following messages will
be transmitted from the UA-700 to the MIDI port [EDIROL UA-700 CONTROL] of your computer.
fig.02-a
Note #00 on
90 00 01
If you press the Sequencer Control switch when the button is lit, the following messages will be
transmitted from the UA-700 to the MIDI port [EDIROL UA-700 CONTROL] of your computer.
fig.02-b
Note #00 on
90 00 01

Send/Return mode

The UA-700 provides a mode that lets you apply effects to the audio data played back by your
computer, and then re-record it on your computer. (See the block diagram.)
Use this when you want to apply effects to existing audio data.
fig.02-5
1. Turn on the power while holding down the Input Monitor switch.
144
Note #04 on Note #04 off
90 04 01 90 04 00
Note messages for Start
Cubase E-2
SONAR E 0
Note messages for Remote
Cubase C-2
SONAR C 0
Note #02 on Note #02 off
90 02 01 90 02 00
Note messages for Start
Cubase D-2
SONAR D 0
Note messages for Remote
Cubase C-2
SONAR C 0
Note #00 off
90 00 00 FA
Note #00 off
90 00 00 FC
