SATAjet 100 B F (RP / HVLP), B P Operating Instructions
■ Gravity flow cups made of PVC or aluminum with different capacities
After unpacking check whether:
■ Paint spray gun damaged
■ Complete scope of delivery

6. Technical Design

Anti-drip device
[1-1]
Round/flat fan control
[1-2]
Material flow control
[1-3]
[1-4] Counter nut for material
flow control
[1-5] Air micrometer (air flow
control)
Air micrometer (air flow
[1-6]
control) locking screw
[1-7] Air piston (not visible)
[1-8] Compressed air connection,
G ¼ (male thread)
ColorCode-System (CCS)
[1-9]
6.1. Air micrometer (air flow control)
[3-101] SATA adam 2 (see 14)
[3-102] Separate pressure gauge
with regulator (see 14)

7. Technical Data

Description
Recommended spray
gun inlet pressure
Recommended Spot
Repair gun supply
pressure
Recommended Com-
pliant gun supply pres-
sure
[1-10] Paint spray gun handle
[1-11] Trigger
[1-12] Nozzle set consisting of air
[1-13] Paint spray gun connection
[1-14] Gravity flow cup connection
[1-15] Paint strainer (not visible)
[1-16] Gravity flow cup
[1-17] Gravity flow cup lid
[3-103] Separate pressure gauge
[3-104] Pressure measurement at
RP
22 psi - 29 psi
7 psi - 22 psi
−
cap pressure >
cap, fluid tip (not visible),
paint needle (not visible)
with QCC
with QCC
without regulator (see 14)
compressed air circuit
HVLP
29 psi 22 psi - 29 psi
−
> 29 psi (air
10 psi)
US
Polyester
−
−
529
