Operating Instructions SATAjet 100 B F (RP / HVLP), B P
Malfunction
Spray gun drips at flu-
id tip ("fluid tip cone").

12. Disposal

Dispose of the completely emptied spray gun as a recyclable material.
To avoid damage to the environment, dispose of the spray material and
release agent separately from the spray gun in an appropriate manner.
Comply with local regulations!

13. After Sale Service

Please refer to your local SATA dealer for accessories, spare parts and
technical support.

14. Accessories

Art. No. Description
6981 Quick coupling nipple G1/4 IG
27771 Air micrometer 0 – 845 with pressure gauge
64030 SATA cleaning set
53090 Air hose
48173 High performance grease

15. Spare Parts

Art. No. Description
1826 Drip-stop for 0.6 l plastic cup
3988 Paint strainer
6395 CCS clip (green, blue, red, black)
9050 Tool kit
15438 Paint needle sealing
25874* O-ring 9 x 1.5
27243 0.6 l QCC quick-change gravity flow cup (plastic)
49395 Screw-on lid for 0.6 l plastic cup
Cause
Contamination be-
tween paint needle tip
and fluid tip.
Damaged nozzle set.
Corrective Action
Clean fluid tip and paint
needle. Heed cleaning
instructions (see chap-
ter 10).
Replace nozzle set (see
chapter 9.1).
Num-
ber
5 ea.
1 ea.
1 set
1 ea.
1 ea.
Num-
ber
4 units
10 pcs.
4 units
1 set
1 ea.
1 ea.
1 ea.
1 ea.
