12. Technical specifications

Dimensions (H × W × D) 194 × 180 × 161
Weight 0.575 kg
Supply voltage 230-240 ~V / 50/60 Hz
Mains current 75 mA
Output 14.8 W / 80 lm/W
Additional switching capacity Incandescent / halogen lamp load
Fluorescent-lamp electronic ballasts
Fluorescent lamps, uncorrected
Fluorescent lamps, series-corrected
Fluorescent lamps, parallel-corrected
Low-voltage halogen lamps
LED < 2 W
2 W < LED < 8 W
LED > 8 W
Capacitive load
Power factor 0.84
Luminous flux / brightness 1184 lm
Efficiency 80 lm/W
Colour temperature 4000 K (neutral white)
Area illuminated Front view 283.1 cm
Colour rendering index Ra ≥ 80
Sensor system Passive infrared
Reach max. 14 m via control dial
Angle of coverage 140°
Time setting 3 min factory setting / 5 s to 15 min via Z-Wave
Twilight setting 2-2000 lux via control dial and with the app
IP / protection class IP44 / II
Z-Wave wireless range approx. 100 m (unobstructed line of vision)
Radio frequency band 868 MHz
Transmitter power ≤ 2.5 mW
1000 W
430 W
500 VA
406 VA
406 VA
1000 VA
16 W
64 W
64 W
88 μF
Side view 113 cm
2 2
– 18 –
13. Troubleshooting
Malfunction Cause
Sensor-switched LED floodlight
Fuse has tripped, not switched
without power
ON, break in wiring
Short-circuit
Sensor-switched LED floodlight
Twilight setting in night-
will not switch ON
time mode during daytime
operation
Mains switch OFF
Fuse has tripped
Detection zone not correctly
adjusted
Sensor-switched LED floodlight Continued movement within
will not switch OFF the detection zone
Sensor-switched LED floodlight
Animals moving in detection
keeps switching ON and OFF
zone
Sensor-switched LED floodlight Wind is moving trees and
switches ON when it should not
bushes in the detection zone
Cars in the street are detected
Sudden temperature changes
due to weather (wind, rain,
snow) or exhaust air from fans
or open windows
Sensor-switched LED
floodlight swaying (moving),
resulting, for example, from
gusts of wind or heavy
precipitation
The device cannot be added Z-Wave controller too far from
(and is not yet added) the device
The device cannot be added It is already added
Status-LED flashing for
No wireless contact with the
1 second every 5 seconds Smart Friends Box or other
Z-Wave controller
Status LED flashing rapidly
Critical fault
all the time
Remedy
Activate or change fuse; turn ON
power switch; check wiring with
voltage tester
Check connections
Reset
Switch ON
Activate, change fuse, check
connection if necessary
Readjust
Check zone and readjust if
necessary or apply shroud
Tilt sensor higher or apply specific
shrouds; adjust detection zone or
fit shrouds
Change detection zone
Change detection zone
Adjust detection zone or install in
a different place
Fit sensor-switched LED flood-
light to a firm surface
Reduce distance from Z-Wave
controller
Install a Z-Wave repeater
Remove device from existing
network
Carry out default reset
Re-start Smart Friends Box or
Z-Wave controller
Reduce distance from Z-Wave
controller
Install a Z-Wave repeater
Briefly disconnect device from the
mains power supply
