wards.
•
The adjustable stop rail (39) must be fixed far
enough in front of the innermost position that
the distance between the stop rail (39) and
the saw blade (5) amounts to a maximum of
5mm.
•
Before making a cut, check that the stop rail
and the saw blade cannot collide.
•
Tighten the locking screw (40) again.
6.1 Use as a bench saw (Fig. 1)
Setting the saw to bench mode (see 5.2.2/6)
Take extra care when starting the cut.
6.1.1 On/Off switch (Fig. 1)
•
The saw can be switched on by pressing the
green pushbutton (a). Wait for the blade (5)
to reach its maximum speed before starting
the cut.
•
The red pushbutton (b) has to be pressed to
switch off the saw.
6.1.2 Setting the cutting depth
•
Undo the locking screw (15) and set the saw
bench (16) to the required cutting depth. The
saw blade (5) should project out of the mate-
rial by a few millimeters.
•
Retighten the locknut (15).
6.1.3 Longitudinal cuts (Figure 20-22)
•
Undo the knurled screw (25) and set the
cross and parallel stop (18) to 90°. Tighten
the knurled screw (25) again.
•
Fit the parallel stop (18) from the right into the
front groove in the saw bench (16).
•
Undo the two knurled screws (26). Carefully
push the stop rail (27) to over the middle of
the saw blade (5) and secure it.
•
Set the parallel stop (18) to the required di-
mension using the scale (c) on the saw bench
(16) and secure it with the locking screw (28).
•
Switch on the saw by pressing the green
button (a).
•
Slide the workpiece slowly and precisely
along the parallel stop (18) to the saw blade
(5).
•
The top saw blade guard (17) will open auto-
matically and the workpiece moves forward.
•
Important: For workpiece widths below 120
mm a push stick (29) must be used in the
area near the saw blade (5) (see Fig. 21)
(supplied). For workpiece widths below 30
mm a push block (d) must be used to move
the workpiece (Fig. 22). The push block is
not supplied. (Available from your specialist
Anl_TC_MS_2513_T_SPK1.indb 27 Anl_TC_MS_2513_T_SPK1.indb 27
GB
dealer)
•
Always push the workpiece through to the
end of the splitter (30) (Fig. 22).
•
After completing the cut the safety hood (17)
will close again automatically to cover the
saw blade (5).
•
Switch off the saw again.
•
Important: Secure long workpieces against
falling off at the end of the cut (e.g. with a rol-
ler stand etc.) (e.g. roller table etc.)
6.1.4. Making cross cuts (Fig. 20/23-24)
•
Fit the cross parallel stop (18) from the front
into the side groove in the saw bench (16).
•
Tighten the locking screw (28) until the cross
and parallel stop (18) can be moved in the
groove in the saw bench (16) with a little play.
•
Undo the knurled screw (25), set the cross
stop (18) to the required angle and secure it.
•
Undo the two knurled screws (26) and slide
the stop rail (27) to the left until it do not touch
the saw blade guard (17) when it is moved
forwards. Retighten the knurled screws (26).
•
Switch on the saw.
•
Press the workpiece firmly against the stop
rail (27) and slide it slowly into the saw blade
(5) together with the cross and parallel stop
(18) to complete the cut.
•
After completing the cut, switch off the saw
again.
6.2. Using as a crosscut saw
Set the saw to crosscut mode (see 6.2.1, 6)
6.2.1 Settings (Abb. 2/3)
•
When the tightening screw (22) is loosened,
you can tilt the machine head to the left by up
to 45°.
•
The turntable (8) can be adjusted from -45° to
+45° by undoing the locking screws.(10)
•
Start the saw by pressing the On/Off switch
(3). The switch must remain pressed during
the sawing work.
6.2.2 Crosscut 90° and turntable 0° (Fig. 2/29)
•
Press the On/Off switch (3) to turn on the saw.
•
Important. Place the material for sawing firmly
on the machine surface and secure it with the
clamp (37) to prevent it from moving during
the sawing process.
•
When you have switched on the saw, wait
until the saw blade (5) has reached maximum
speed.
•
Press the release lever (1) and, using the
handle (2), apply steady and light downward
