is the same as that for your mains.
Secure the clamp (37) on the top of the stop
rail using the screw.
5.1 Setting up the saw (Fig. 1-4)
Insert the two workpiece support clips (20)
in the mounts (13) provided on the side of
the tool and fasten them in place with screws
(36).
To prevent the saw from toppling backwards,
the additional foot (a) must be pulled out of
the equipment (Fig. 4).
5.2 Converting the combination saw (Fig. 1-8)
The saw has two working positions:
A: Bench circular saw (Fig. 1)
B: Crosscut and miter saw (Fig. 2)
Convert the combination saw can be conver-
ted exactly as described below, otherwise the
components may be damaged.
Important: Pull out the mains plug before you
convert the saw.
When it is supplied, the saw will be in mode A
(bench circular saw)
5.2.1 Converting the saw for crosscut mode
First undo the lock nuts (15).
Applying slight counterpressure, hold down
the saw table (16) and release the locking
lever (24) (move downwards).
Important. The integral resetting springs
will automatically lift the equipment. Do not
simply let go of the saw handle (16) but allow
the saw handle to rise slowly, applying slight
counterpressure as it does so.
Press the release button (1) and lower the
machine head using the handle (2) until the
bottom saw blade guard (14) completely co-
vers the saw blade.
Insert the safety pin (23) to secure the saw in
the bottom position. This will reroute the pow-
er from switch (3) to switch (4).
Release the locking lever (24) (move it down-
wards)
Undo the locking screw (15) and lower the
saw bench (16) to the required cutting depth.
Retighten the locknut (15).
Re-tighten the locking lever (24).
Lowering the saw bench (16) will block the
safety pin (23) by means of the locking fork
(24) so that it cannot be pulled out.
The saw has now been converted back to
bench mode.
Anl_TC_MS_2513_T_SPK1.indb 25
Anl_TC_MS_2513_T_SPK1.indb 25
GB
5.2.2 Converting the saw for bench mode
Position the machine head vertically and set
the turntable (8) to 0°.
Secure the locking screws (10) and tightening
screw (22).
Place the bottom saw blade cover (14) on the
turntable (8) ensuring that the two rear feet
on the cover (14) engage securely behind the
stop rail (7).
First undo the lock nuts (15).
Move the saw bench (16) upwards with one
hand and at the same time push the machi-
ne head downwards with your other hand
using the handle (2). The saw blade (5) must
completely disappear into the slit in the saw
bench (16).
Retighten the locknut (15).
Press the release button (1) and lower the
machine head using the handle (2) until the
bottom saw blade guard (14) completely co-
vers the saw blade.
Insert the safety pin (23) to secure the saw in
the bottom position. This will reroute the pow-
er from switch (3) to switch (4).
Undo the locking screw (15) and lower the
saw bench (16) to the required cutting depth.
Retighten the locknut (15).
Lowering the saw bench (16) will block the
safety pin (23) by the locking fork (24) so that
it cannot be pulled out.
The saw has now been converted back to
bench mode.
5.3 Adjusting the saw (Fig. 1/2)
Undo the locking screw (10) approx. 2 turns
to adjust the turntable (8).
The turntable (8) has locking points at angles
of 0°, 5°, 10°, 15°, 20°, 25°, 30°, 35°, 40° and
45°. Once the turntable (8) is engaged, the
setting must also be secured by tightening
the locking screw (10).
If different angle settings are required, the
turntable (8) may be secured in position using
only the locking screw (10).
Lightly press the machine head down while
at the same time pulling the retaining pin (23)
out from the motor mounting; this causes the
saw to move down to the lower working po-
sition. Turn the safety pin (23) through 90° so
that the machine head remains unlocked.
Swing up the machine head.
When the tightening screw (22) is loosened,
you can tilt the machine head to the left by up
to 45°.
Check the mains voltage against the voltage
- 25 -
