Preparation

Before You Begin

Tools and Parts Needed

• Dual Fuel models only - 40 or 50 Amp power supply
cord kit with strain relief (depending on local code).
Note: Not necessary for Canadian installations, cord is
preinstalled at factory.
• Measuring Tape
• Phillips Head Screwdriver
• 1¼" Wrench
• Pencil
• T-20 Torx Screwdriver
• Screws (2) and Anchors (2) for Anti-Tip Bracket (Style
will vary depending on mounting surface)
• Level
• Drill and Drill Bit (3/16" masonry bit for concrete
screws)
• Soapy Water
• Safety Gloves and Goggles
• Cloth or Cardboard (Optional - to Protect Floor)
• Pipe Wrench
• Gas-approved Teflon Tape
• Channel Lock Pliers
• Gas Leak Test Solution
• Gas Supply Line (½" NPT Minimum)
• Gas Shutoff Valve

Parts Included

• Anti-Tip Bracket
• 2 wood screws
• 2 anchorless concrete screws
• Foam Tape (unless already installed on underside of
cooktop sides)
• Terminal Lugs (For Use With Hard Wire Installations)
Note: Terminal lugs not necessary for Canadian
installations.
9000989333 Rev D
Additional Parts Needed for Hard-Wired
Installations
Dual Fuel models only
• Flexible conduit
• Torque wrench
Note: Power supply cord kit is not necessary for hard-wired
installations.

Remove Packaging

• .If straps are present, cut the straps.
• Cut plastic down back of unit making sure not to cut the
unit.
• Remove plastic film.
• Lift cardboard around the top portion of the unit, off of
the unit.
• Remove cardboard corner posts, making sure that any
posts or other packaging materials running between
corner posts are also removed.
• Remove all internal packaging and tape.

Installation Checklist

Please refer to the pages following for complete installation
instructions. Use this checklist to verify that you have
completed each step of the installation process. This can
help you avoid common mistakes.
___ 1. Before installing the range, be sure to verify the
cabinet dimensions are correct for your unit and
that the required electrical and gas connections are
present.
___ 2. Refer to the installation manual for content
regarding Safety, Cabinet Dimensions, Removing
Packaging, Electrical Installation, Gas Connection,
Testing the Installation and Customer Service.
___ 3. Removing the oven door and warming drawer prior
to installation reduces the unit weight and makes
the range easier to move. Additionally the removal
of the oven door provides access to handhold for
lifting.
___ 4. Move the range unit into place in front of the
installation opening, leaving the bottom packaging
on the unit to avoid damaging flooring.
___ 5. Plug the range into a properly configured
receptacle.
___ 6. Protect the flooring from damage, then slide the
unit all the way into place, making sure to route the
power cord correctly.
___ 7. Reinstall the oven door removed in step 3 above.
