OFF - The photocells are included in the Ok safety check cycle which is
carried out before each manoeuvre. For connection, refer to the enclosed
diagrams.
Dip 10 .................................................................. Unchecked edge (BAR)
Activates the rubber edge device control logic.
ON - The edge devices are excluded from the safety check cycle which is
carried out before each manoeuvre; however their logic state is analysed
(for connection, refer to the typical method of connecting infrared edges with
continuously active beams). This is used to connect IR edges which have not
been checked or have internal self-diagnosing system, and always provide
a voltage-free output contact.
OFF - The IR edge devices are included in the Ok safety check cycle which
is carried out before each manoeuvre. For connection, refer to the enclosed
diagrams.
6.2) Trimmer-set functions
TW.PED Sets the partial operation time of a sliding gate which is being used
for both vehicles and pedestrians.
TW Sets the operation time during both the opening and closing phases
(adjustable from 3 to 210 seconds).
TCA Sets the dwell time, after which the gate closes automatically (from
1 to 120 seconds).

6.3) LED functions

A series of LEDs allows to check or detect any operating anomalies in the
control unit or on the connected devices.
(DL1) Stays on when supplied with mains power and with F1 fuse intact.
(DL2) Comes on when the motor is activated during closing.
(DL3) Comes on when the motor is activated during opening.
(DL4) Comes on following the Start command or the activation of the first
radio-receiver channel.
(DL5) Goes off when the block command is activated.
(DL6) Goes off when photocells are not aligned, i.e. when obstacles are
present. When Dip-switch 9 is OFF, the photocells and related leds
are only activated during manoeuvring.
(DL7) Goes off when the gate is in the completely open position, if provided
with end-of-stroke device.
(DL8) Goes off when the gate is in the completely closed position, if pro-
vided with end-of-stroke device.
(DL9) Comes on at the Start command for pedestrian gate.
(DL10) Comes on with manual opening command.
(DL11) Comes on with manual closing command.
(DL12) Goes off when the pneumatic edge is activated. When Dip-switch
10 is OFF, the edge and its related LED are only activated during
manoeuvring.
(DL13) Comes on when the safety ring is closed.
(DL14) Comes on when the safety micro has stepped in.

7) MAINTENANCE AND DEMOLITION

The maintenance of the system should only be carried out by quali-
fied personnel regularly. The materials making up the set and its packing
must be disposed of according to the regulations in force. Batteries must
be properly disposed of.
The descriptions and illustrations contained in this manual are not
binding. The Company reserves the right to make any alterations
deemed appropriate for the technical, manufacturing and commercial
improvement of the product, while leaving the essential product fea-
tures unchanged, at any time and without undertaking to update the
present publication.
