Warning! It is prohibited to use the tool to
chop material for composting because of the
potential danger to persons and property.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case
of misuse. The user / operator and not the manu-
facturer will be liable for any damage or injuries of
any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

Speed n : ............................................. 1200 rpm
0
Cutting width of the grass cutter: ............ 100 mm
Cutting width of the shrub shears ........... 190 mm
Cutting thickness of the shrub shears ........ 8 mm
Running time max.: .................................100 min
Battery pack: ............. Li-Ion / 10,8 V d. c. / 1.3 Ah
Charging time: ................................................ 2 h
L sound pressure level: ...................... 61 dB (A)
pA
L sound power level: ......................... 81 dB (A)
WA
K uncertainty ........................................... 6 dB (A)
Vibration a : .......................................... 5.5 m/s
hV
K uncertainty ............................................1,5 m/s
Weight: .......................................................1.4 kg
Sound pressure level
at the operator's ear .............................. 77 dB (A)
K uncertainty ........................................... 3 dB (A)
Battery charger
Mains voltage.....................100-240 V ~ 50-60 Hz
Output
Rated voltage .......................................... 13 V DC
Rated current: .......................................... 900 mA
Anl_GE_CG_10_8_Li_WT_SPK7.indb 16 Anl_GE_CG_10_8_Li_WT_SPK7.indb 16
GB
•
The vibration emission level has been measu-
red in accordance with a set of standardized
criteria and can be used to compare one po-
wer tool with another.
•
The specified emission level can also be
used to make an initial assessment of the ex-
posure to vibrations.
•
The vibration emission level may vary from
the level specified during actual use, depen-
ding on the way in which the power tool is
used.
•
Try to keep the impact from vibrations as low
as possible. Exposure to vibrations can be re-
duced by wearing gloves when using the tool,
for example, and by limiting the amount of
operating time. This includes the full cycle of
operation (e.g. times when the power tool is
switched off and times when the tool is swit-
ched on but no working load is applied).

5. Before starting the equipment

5.1 Charging the battery pack (Figure 3, 4)
•
Connect the charger to the charging station
(Figure 3).
•
Check that your mains voltage is the same
as that marked on the rating plate of the bat-
tery charger. Plug the battery charger in a
socket-outlet. The red LED (Figure 4 / Item 1)
comes on to indicate that charging voltage is
2
available.
2 •
The battery pack is being charged. An empty
battery pack requires a maximum charging
period of 2 hours. The temperature of the bat-
tery pack may rise slightly during the charging
operation. This is normal.
•
As soon as battery pack is fully charged, the
red LED (Fig. 4/Item 1) extinguishes
If the rechargeable battery fails to charge, check
whether there is voltage at the socket outlet.
Timely recharging of the battery pack will help
it serve you well for a long time. Recharging is
always necessary when you notice a drop in the
tool's performance.
Never allow the battery pack to become fully di-
scharged. This will cause it to develop a defect.
