Panneau Arrière - Sony BDV-T10 Mode D'emploi

Panneau arrière
SPEAKER
CENTER SUBWOOFER
A Borne LAN (100) (page 28)
B Prises COMPONENT VIDEO OUT
(page 22)
C Prise VIDEO OUT (page 22)
D Emplacement EZW-T100 (page 60)
E Borne AM (page 26)
F Prise COAXIAL 75Ω FM (page 26)
G Prise A.CAL MIC (pages 30, 70)
H Prises AUDIO (AUDIO IN L/R) (page 24)
I Prises TV (AUDIO IN L/R) (page 23)
16
FR
COMPONENT VIDEO OUT VIDEO OUT
Y
P / C P / C
B B R R
HDMI OUT
LAN(100)
SPEAKER DMPORT
DC5V
700mA MAX
FRONT R FRONT L SUR R SUR L
J Emplacement EXT (page 27)
K Prise TV (DIGITAL IN OPTICAL)
L Prise SAT/CABLE (DIGITAL IN
M Prise DMPORT (DIGITAL MEDIA PORT)
N Prise HDMI OUT (page 22)
O Prises SPEAKER (page 21)
*
Vis*
EZW-T100
SAT/CABLE TV EXT
DIGITAL IN DIGITAL IN DC5V 500mA MAX
COAXIAL OPTICAL
(page 23)
COAXIAL) (page 24)
(page 24)
ATTENTION
Ne retirez pas les vis, à moins que vous
installiez l'EZW-T100.
ANTENNA
COAXIAL 75
FM
AM
TV AUDIO
L L
A. CAL MIC
ECM-AC2
R R
AUDIO IN AUDIO IN
