5.5.3 Assembly on supports

There are holes in the box for wall or floor mounting.
Fig. 9
The box can be also mounted on the pole mount
adapter or the corner adaptor .
Fig. 10 WASEX+NXCOL.
Fig. 11 WASEX+NXCW.
10

6 Installation

Never exceed performance specifications.
Make all connections in a non-explosive
atmosphere.
Before starting any operation, make sure
the power supply is disconnected.

6.1 Installing the pump tank

We recommend filling the tank with water
at ambient temperature. If using the pump
at temperatures below 3°C (37.4°F) add
some glass cleaner antifreeze liquid to the
water. The liquid used must have an ignition
temperature (IEC 60079-4) at least 50K
above the maximum surface temperature
of the equipment. The liquid used must not
cause ignition of the atmosphere.
6.2 Connection of the power
supply line
When commencing installation make sure
that the specifications for the power supply
for the installation correspond with those
required by the device.
Check that the power supply socket and
cable are adequately dimensioned.

6.2.1 Connection of the solenoid valve

For further information, refer to the product use and
installation manual.
MNVCWASEX_2013_EN
