Various Settings
Press the [SELECT] (Upper/Lower)
1
button to select the DISP Data.
2
Press the [ENTER] button.
The display data import mode is
activated.
Press the [SELECT] (Upper/Lower)
3
button to select media types.
4
Press the [ENTER] button.
• When using a CD-R:
The front panel opens automatically
and, if a CD has already been loaded
into the main unit, it will automatically
eject.
• When using a memory stick:
If the memory stick containing the
images is not inserted, the front panel
opens automatically.
5
Insert your selected media.
Press the [
6
button to close the front panel.
Press the [SELECT] (Upper/Lower)
7
button from the display type to
which you want to import the data:
[Motion picture] - [Wall paper] -
[Slideshow]
When the button is pressed, the media
type changes display type in the
following order.
Motion picture
Slideshow l Motion picture l MMM
Press the [SELECT] (Upper/Lower)
8
button to select files.
9
Press the [ENTER] button.
Press the [SELECT] (Upper/Lower)
10
button to select the image data you
want to overwrite.
82
(OPEN/EJECT)]
l l
Wall paper
11
Press the [ENTER] button.
Begin importing the data into the main
unit. If the data has already been
imported, the data will be overwritten.
When importing
[Completed] will appear and the front
panel opens automatically, and CD-Rs
will automatically eject. Press the [
(OPEN/EJECT)] button to close the
previous panel.
Press the [CUSTOM] or [RTN]
12
button to exit sound adjustment
mode.
ATTENTION
<When using a memory stick>
• Data downloaded from the ECLIPSE web
site (E-iSERV) can be saved in folders on
the Memory Stick as follows:
MSFTEN
User creation
DISP
XXXXXXX.oel
• Files that can be imported into the main unit
are created automatically when downloaded
from the E-iSERV web site.
<When using a CD-R>
• The main unit can only import files from CD-
R that have been
directories.
XXXXXXX.oel
File extension
• Disc formats that may be used are as
follows:
• CD-ROM (MODE 1)
• CD-ROM (MODE2_FORM 1)
*CD-ROMs written in
cannot be read.
has completed,
Automatic creation
File extension
written with root
Automatic creation
MODE2_FORM2
