Press the [SELECT] (Upper/Lower)
3
button.
Press the [SELECT] (Upper/Lower)
button to set illumination color
follows:
Blue/Red l Blue/Green l Blue/Amber
l All Red l All Green l All Amber l
Blue/Red l MMM
4
Press the [ENTER] button.
The selected settings will take effect.
Press the [CUSTOM] or [RTN]
5
button to exit display adjustment
mode.
Changing display type
(DISP Type)
You can change the display type (background,
spectrum analyzer and slide show).
Press the [SELECT] (Upper/Lower)
1
button to select the DISP Type.
2
Press the [ENTER] button.
The display type setting mode is
activated.
Press the [SELECT] (Upper/Lower)
3
button to select the setting item.
When the button is pressed, the
setting item changes in the following
order.
Background l S/A l Slide show l
GPS INFO* l Background l MMM
*: Only when the optional GPS unit is
connected.
4
Press the [ENTER] button.
Switches among
modes.
Making changes with Display Adjustment Mode
Changing Background
(Background)
You can change the background.
as
1
2
3
4
5
the adjustments
Press the [SELECT] (Upper/Lower)
button to select the Background.
The selected item is highlighted.
Press the [ENTER] button.
The display type setting mode is
activated.
Press the [SELECT] (Upper/Lower)
button to select the setting item.
When the button is pressed, the
background changes in the following
order.
Motion picture 1 l Motion picture 2 l
Wall paper 1 l Wall paper 2 l
Wall paper 3 l Wall paper 4 l
Standard (Background OFF) l
Motion picture 1 l MMM
Press the [ENTER] button.
The selected settings will take effect.
Press the [CUSTOM] or [RTN]
button to exit display adjustment
mode.
