Spare parts list:
PILOT Premium-HVLP-Adhesive
Gravity-Feed Cup
V 10 711
Item Designation Qty. Item number
1 Air head nut compl. 1 V 20 700 05 000
2 Air head 1 V 10 711 30 XX5*
3 Material nozzle 1 V 10 711 40 XX3*
5 Air distributor ring 1 V 10 701 14 100
6 Gun body with bushings 1 V 10 705 01 000
7 Needle seal compl. 1 V 09 001 72 000 ♦
8 Packing screw 1 V 10 701 02 000
9 Material needle 1 V 10 711 30 XX3*
10 Driving bushing 1 V 10 306 06 000
11 Counter screw 1 V 10 701 03 000
12 Needle spring 1 V 10 701 40 000
13 Spring cap 1 V 10 701 04 000
14 Sealing cone 1 V 11 700 11 200
15 Lock washer 1 V 10 151 23 000
16 Guide bushing 1 V 10 600 05 200
17 Packing 1 V 09 101 02 020 ♦
18 Packing screw 1 V 10 600 29 100
19 Regulating screw 1 V 10 701 06 000
20 Valve packing gland 1 V 10 701 07 000
21 Valve shaft seal 1 V 11 750 20 000
22 O-ring 1 V 09 102 38 001 ♦
23 Valve shaft compl. 1 V 10 701 08 300
24 Valve cone 1 V 10 701 08 000
25 Valve spring 1 V 10 701 41 000
26 Cap screw 1 V 11 700 27 400
27 Bushing, air volume reg. 1 V 10 701 05 000
28 Seal, air volume reg. 1 V 10 701 09 000 ♦
29 Air volume regulation 1 V 10 701 10 000
30 Lever screw 1 V 10 301 09 000
31 Trigger 1 V 10 701 11 000
32 Lever shank screw 1 V 10 600 20 100
33 Limiting pin 1 V 10 701 12 000
34 Colour ring 1 V 10 701 13 300
35 Double nipple 1 V 00 101 01 000
36 Cup compl. 1 V 00 130 00 060
37 Double nipple
39 Spring washer 1 V 10 701 11 100
PILOT Premium-HVLP-Adhesive
Material connection
V 10 712
Qty. Item number
1 V 20 700 05 000
1 V 10 711 35 XX5*
1 V 10 711 40 XX3*
1 V 10 701 14 100
1 V 10 706 01 000
1 V 09 001 72 000 ♦
1 V 10 702 02 000
1 V 10 306 07 XX3*
1 V 10 306 06 000
1 V 10 701 03 000
1 V 10 701 40 000
1 V 10 701 04 000
1 V 11 700 11 200
1 V 10 151 23 000
1 V 10 600 05 200
1 V 09 101 02 020 ♦
1 V 10 600 29 100
1 V 10 702 06 000
1 V 10 701 07 000
1 V 11 750 20 000
1 V 09 102 38 001 ♦
1 V 10 701 08 300
1 V 10 701 08 000
1 V 10 701 41 000
1 V 11 700 27 400
1 V 10 701 05 000
1 V 10 701 09 000 ♦
1 V 10 701 10 000
1 V 10 301 09 000
1 V 10 701 11 000
1 V 10 600 20 100
1 V 10 701 12 000
1 V 10 701 13 300
1 V 00 101 01 000
1 V 00 101 04 pre
1 V 10 701 11 100
28
* Please specify the respective size when ordering spare parts.
Nozzle equipment as selected: ▪ 0,3 ▪ 0,5 ▪ 0,8 ▪ 1,0 ▪ 1,2 ▪ 1,5 ▪ 1,8 ▪ 2,0 ▪ 2,2 ▪ 2,5
▪ 3.0 ▪ 3,5 mm ø
We recommend to keep all parts printed in bold (wearing parts) in stock.
Repair sets
For the manual spray guns PILOT PREMIUM ,-HVLP
WALTHER has repair sets with all wearing parts available. The parts are marked in bold in the
spare parts list.
PILOT PREMIUM
Gravity-Feed Cup (FB)
PILOT PREMIUM
Material connection (FA)
PILOT PREMIUM FB HVLP /
PLUS
PILOT PREMIUM FA HVLP /
PLUS
PILOT PREMIUM FB HVLP
PILOT PREMIUM FA HVLP
PILOT PREMIUM
Gravity-Feed Cup (FB)
PILOT PREMIUM
Material connection (FA)
PILOT PREMIUM FB HVLP
PILOT PREMIUM FA HVLP
Seal set
The seal set contains all item numbers marked with ♦.
PILOT PREMIUM /-HVLP /-HVLP
PLUS
, -HVLP and the adhesive versions
PLUS
Item number
Standard version V 16 107 01 ..3
Standard version V 16 107 02 ..3
Medium-pressure vers. V 16 107 03 ..3
Medium-pressure vers. V 16 107 04 ..3
Low-pressure version V 16 107 05 ..3
Low-pressure version V 16 107 06 ..3
Standard adhesive version V 16 107 15 ..3
Standard adhesive version V 16 107 16 ..3
Low-pressure adhesive vers. V 16 107 11 ..3
Low-pressure adhesive vers. V 16 107 12 ..3
V 17 107 00 000
