Installation, assembly

Personnel:
8.1

Electrical connection

The Rotorspray integra
(automation technology) and has left the factory in a perfectly safe technical condition.
The user must observe the information and warning notes contained in this Operating
Manual in order to maintain this condition and to ensure operation without hazard.
If it is to be assumed that operation without hazard is no longer possible, then the
Rotorspray integra
operation.
This is the case if:
n the Rotorspray integra
n the Rotorspray integra
e.g. after longer storage periods under unfavorable conditions.
The rotor spray is protected against interference effects according to the NAMUR
recommendations and EN 61000-6-4:2001.
8.2

Connectors

8.2.1
Connection to Rotorspray integra
The Rotorspray integra
works. Only the bridges for the activation/deactivation of the monitoring functions have to
be installed.
Attachment plug M12 (coupling)
straight version
Attachment plug M12 (coupling)
offset version
n Qualified electrician
n Service personnel
PLUS is constructed and tested according to IEC 61131-2
PLUS is to be taken out of service and safeguarded against unintentional
PLUS
shows visible damage,
PLUS
no longer appears to function,
PLUS
PLUS
has an 8-pole plug. The corresponding coupling is prewired ex
27
Installation, assembly
417101448 Rev. 04-02.2019
