Use

The rotor spray with integrated speed regulator, Rotorspray integra
automatic application of adhesives, sealants and lubricants in drilled holes in the diameter
range from 8 bis 100 mm.The automobile sector represents a significant range of
applications.
The Rotorspray integra
EP (Article No. 295219).
The product (reactive adhesives, oils or other liquids) is delivered into the rotating rotor
disc via the needle of the dispensing valve. The product is applied in a ring shape in the
drilled hole to be wetted due to the rotation of the rotor disc and its construction. Preferred
use is horizontal or from above.
Only low viscosity adhesives or oils can be processed using the Rotorspray integra
The size of the rotor disc and the length of the shaft are variable within broad limits in
order to take into consideration the differing drilled hole diameters and lengths to be
wetted.
The customer's PLC is responsible for the coordinated activation of dispensing valve and
Rotorspray integra
The Rotorspray integra
connection with the super ordinate control system. A release signal input and a ready
reply signal output are integrated to coordinate the operation sequence.
In addition to the actual speed regulator, the Rotorspray integra
current limitation and adjustable acceleration monitoring.
The rotor spray is subject to the limits stated in the technical data regarding the output
available to accelerate the shaft and the rotor disc.
Data
Largest rotor disc diameter:
Largest shaft diameter:
Longest shaft (with bearing bush):
PLUS is generally used together with a dispensing valve
PLUS .
PLUS
is integrated in production facilities and works there in
19
Use
PLUS
, is used for the
PLUS
PLUS also has a switch-on
Value Unit
40 mm
6 mm
600 mm
