Lenze APPLICATION−I/O PT E82ZAFAC010 Instructions De Montage page 34

4 Electrical installation
X3.1/ Signal type Function
1U/2U Analog
inputs
1I/2I
X3.2/ Signal type Function
Analog
62
outputs
63
9 −
1)
Output level 0 ... + 10 V or 0/+4 ... +20 mA: adapt offset (C0422) and gain (C0420).
34
Actual value or setpoint inputs (master
voltage)
Change range with jumper and C0034
Actual value or setpoint inputs (master
current)
Change range with jumper and C0034
Output frequency
Motor current
Internal, stabilised DC voltage source for
setpoint potentiometer
l
Level
(Lenze setting: bold print)
0 ... +5 V
0 ... +10 V
−10 V ... +10 V
0 ... +20 mA
+4 ... +20 mA
+4 ... +20 mA (open−circuit
monitored)
Level
(Lenze setting: bold print)
Voltage output:
0 ... +6 V
1)
0 ... +10 V
Current ouput:
(0 ... +12 mA)
1)
0 ... +20 mA
1)
+4 ... +20 mA
+5.2 V
EDK82ZAFAC−010 DE/EN/FR 6.0
