Connections to the Computer

Connection
3
(Example of connections)
2
NOTES
The drive's ON/OFF power operations are coupled to the computer so that when
the computer is turned on or off, the drive will be automatically turned on or off.
The drive's power is automatically turned on or off by connecting or disconnect-
ing the interface cable.
CAUTION
Do not connect any other cable in place of the interface cable which is supplied
with the drive.
(Doing so may damage the drive and/or Computer.)
Connect the drive directly to the Computer.
No guarantees can be made for the operation if it is connected via a USB hub.
While the drive is still connected to the Computer, do not turn off the drive's
power when the Computer is operating.
When using this drive with USB bus power, we recommend using this drive alone
(other than USB mouse,USB keyboard,etc.).
1
1 Turn your computer on.
2 Connect the end of the interface
3 Connect the end of the interface
cable (included) with the smaller
of the two plugs to the drive's
interface connector.
cable with the larger of the two
plugs to the Computer's USB
port.
The drive's power is now turned on
automatically, and the POWER/BUSY
indicator lamp lights up in green.
E
11
