5 Product information

5.1 Type key
Example : ElectronicControl MT6
ElectronicControl
M
T
6
5.2

Technical data

Maximum operating pressure
Setting range
Maximum flow
Maximum water temperature
Minimum water temperature
Maximum environment temperature 50 °C
Input voltage
Protection current
Operating mode
Class of protection
Protection fuse of the ElectronicCo-
ntrol input (fig. 4, Pos. 3)
Protection fuse of the motor input
(fig. 4, Pos. 4)
5.3 Scope of delivery
• ElectronicControl prewired (fig. 2, Pos. 2)
• EMC filter (fig. 2, Pos. 6)
• Operating instruction
5.4 Accessories

5.4.1 Accessories required

• A tank of minimum 2 liters (to be placed at the ElectronicControl discharge side,
see fig. 2, Pos. 4).
• Check valve (to be placed directly at the ElectronicControl suction side, see fig.
2, Pos. 3).
5.4.2 Accessories as option
• Flow switch - dry running protection.
• Insulation valves.
19
Automatism type with frequency inverter
Electrical supply of the ElectronicControl
1~230V
Electrical supply of the motor
• T = 3~230V
• M = 1~230V
Maximal current delivered in A
15 bar
0.5 up to 12 bars
15 m³/h
40 °C
0 °C
1~230 V, 50/60 Hz
+20% of the nominal current as set during 10s
S3: 30% (3 s ON – 7 s OFF)
IP55
I: 20A, type: gG, U: 500Vac,
breaking capacity I1: 120kA, size: 10 x 38mm
I: 20A, type: high speed, U: 690Vac,
breaking capacity I1: 100kA, size: 10 x 38mm
