Press the push-button
can navigate in both submenus SETTINGS or HISTORIC.
SETTINGS
This submenu allows the setting of the ElectronicControl according to the
installation and the pump.
HISTORIC
This submenu displays the various counts and alarms recorded.
To select a submenu, use the the push-buttons
select it.
The values displayed in the various parameter can be changed via the push-but-
tons
and the next parameter is displayed on the screen. With the push-button
you exit SETTINGS (no saving of the last change) or HISTORIC menu and go back
to STANDARD display mode (or SERVICE).
NOTE: The data are saved in non-volatile memory, this allows to save data even
after switching off.

6.3.1 Menu description

Display
NET P P SET
02.0 bar 02.0 bar
F P SET NET P
50 02.0 bar 02.0 bar
MENU
LANGUAGE
ENGLISH
I. MAX. PUMP
OFF
Installation and operating instructions Wilo-ElectronicControl
for 3 seconds to set the ElectronicControl. The user
or . With the push-button
Menu level 1
Q
1
SETTINGS
or
the new value selected is validated
Menu level 2 Description
Display in STANDARD
mode
Display in SERVICE
mode
rotation frequency
(Hz) + pressure setting
(bar) + networkpres-
sure (bar) + flow
switch detection
(1 or 0)
Menu settings
LANGUAGE Language setting
I. MAX. PUMP Nominal current set-
ting as mentioned on
the identification plate
of the pump
, then push to
English
22
