Display
PUMP CYCLES
30
POWER ON
30
MAX PRESSURE
0,0 BAR
ALARM COUNT
SHT CIRCUIT 15
ALARM COUNT
OV CURRENT 10
ALARM COUNT
OVER T 5
ALARM COUNT
DRY RUN 6

6.3.2 Manual mode

We can access to this mode via the push-button
This mode is fugitive and you shall keep pushing on the push-button
it working.The pump starts at maximum frequency. When releasing it the pump
slows down up to complete stop.

6.3.3 Automatic mode

This mode allows an automatic setting of the pressure whatever the flow is.
You can access to this mode by pushing on the push-button
on.
The working condition of this mode can be set in the SETTINGS menu.
7 Installation and electrical connection
DANGER! Risk of death!
An improper installation and electrical connections can result in a risk of fatal
injury.
• The installation and electrical connections should only be done by a qualified
electrician and in compliance with the regulations in force.
• Follow all accident prevention regulations!
• Before installation and electrical connection, switch off the product/station
shall (no voltage) and be sure it cannot be switched on again without any
control!
• Disconnect the mains plug!
Installation and operating instructions Wilo-ElectronicControl
Menu level 1 Menu level 2
PUMP CYCLES
POWER ON
MAX PRESSURE
ALARM COUNT
SHT CIRCUIT
ALARM COUNT
OV CURRENT
ALARM COUNT
OVER T
ALARM COUNT
DRY RUN
Description
Total number of pump
cycles, one cycle
includes one start and
onr stop.
Number of Electronic-
Control switching on
Storage of the maxi-
mum pressure reached
in the installation (bar).
Total number of short
circuits
Total number of over-
currents
Total number of
exceeding
temperatures
Number of dry running
. The led is off.
to get
. The led
English
is
24
