EINHELL OPAL Instructions De Montage page 12

The delivery package for the 3-panel, 5-panel and
6-panel greenhouse contain more wind bracing
elements than you will need for assembly.
Bottom illustration: Assembly preview / reference
diagram (roof): 3-panel greenhouse
Page 80
Top illustration: Assembly preview / reference
diagram (roof): 4-panel greenhouse
Bottom illustration: Assembly preview / reference
diagram (roof): 5-panel greenhouse
Page 81
Top illustration: Assembly preview / reference
diagram (roof): 6-panel greenhouse
Bottom illustration: Assembly preview / reference
diagram (roof): 7-panel greenhouse
Important note: Please note that on a 7-panel
greenhouse no wind bracing is inserted between the
two middle segments.
Page 83
Installation of the base assembly
Important note: Before proceeding to part 2 of the
assembly instructions, you will need to position your
greenhouse in its final position and attach it to its
base (concrete, brickwork or steel base). Later on it
will no longer be possible to move the greenhouse.
If you are positioning your greenhouse on a
concrete / brickwork base, continue with this
assembly step. If you have purchased the steel
base (not included as part of the standard delivery
package), then install it as described in the assembly
instructions for the steel base.
Anchoring on a concrete / brickwork base
The following additional installation materials are
required for anchoring the greenhouse on a concrete
or brickwork base (not included in the delivery
package):
- Anchor fittings / dowels
- Hexagon-head wood screws
- Washers
12
ABA_OSR_Teil1_Titel+GB.pmd 12
You will require 1 each of these items for every floor
corner connector and 2 each for every floor gusset
plate and the mounting bracket.
Please note: Use anchor fittings / dowels which
are suitable for a concrete / brickwork base.Holes
need to be pre-drilled in the base for the anchor
fittings / dowels.
To mark the holes, position the greenhouse on the
base and mark the positions of the holes for the
mounting brackets.
Page 86
Optional accessories (not included in the
delivery package)
Art. no. 36.405.90: Anchoring set BD4 (4 x ground
anchors)
Art. no. 36.405.91: Anchoring set BD6 (6 x ground
anchors)
Note:The anchoring set is used to secure the
greenhouse or the steel base in the ground. Please
refer to the overviews below for information about the
number of anchoring sets required for your particular
greenhouse. The positions at which the individual
ground anchors are secured are marked with circles.
In order to fix the exact positions of the ground
anchors, position the greenhouse in its final position.
Then mark the positions where the ground anchors
will be installed.
Middle illustration: View from above, 3-panel
greenhouseAnchor sets required: 2 x sets BD4
(art. no. 36.405.90)
Bottom illustration: View from above, 4-panel
greenhouseAnchor sets required: 1 x set BD4
(art. no. 36.405.90) + 1 x set BD6 (art. no. 36.405.91)
Page 87
Top illustration: View from above, 5-panel
greenhouseAnchor sets required: 1 x set BD4
(art. no. 36.405.90) + 1 x set BD6 (art. no. 36.405.91)
Middle illustration: View from above, 6-panel
greenhouseAnchor sets required: 1 x set BD4
(art. no. 36.405.90) + 1 x set BD6 (art. no. 36.405.91)
Bottom illustration: View from above, 7-panel
greenhouseAnchor sets required: 1 x set BD4
(art. no. 36.405.90) + 1 x set BD6 (art. no. 36.405.91)
