3.3

REMOTE CONTROL

The remote control is the interface between the user and the air conditioner. It is therefore particularly important to familiarize
yourself with the parts of the remote control that relate to this interface.
All the references indicated in the following paragraphs refer to figure 29 on page 8 (unless otherwise specified).
3.3.1

Description of the remote control

Buttons (fig. 29): used to set or bring up machine functions.
T1
ON/OFF (standby).
T2
ECONOMY key.
T3
Night well-being mode.
T4 Operating mode selector.
T5 Fan speed selector.
T6 Button for setting timer and programs.
T7 Button for increasing (+) or decreasing (-) the temperature/time settings.
T8 Button for activating the FREE COOLING air change system (not available in this model).
T9 Movable baffle adjustment On/Off button.
T10 Reset button.
T11 Program start button.
Display (fig. 29): shows the operating state and the values of the settings being carried out.
D1 Fan speed or automatic operating mode indicator (AUTO).
D2 Heating.
D3 Cooling.
D4 Dehumidifier only.
D5 Air change activation (not available in this model).
D6 Night operation switch.
D7 Automatic operation switch.
D8 First operating program switch.
D9 Second operating program switch.
D10 Temperature indicator (thermometer) or time indicator (H/M).
D11 ECO activation of the economy function
The remote control is also equipped with a sliding cover that can be positioned so as to permit access only to the ON/OFF, ECO-
NOMY MODE and NIGHT MODE buttons.
3.3.2

Main switch-on and running management

To manage the appliance with the remote control, it will be necessary to have activated the main switch which is included on the
electrical power supply line (the technician that installed the appliance could offer more details regarding the position), or insert
the power plug of the appliance into the socket of the system.
The machine is fitted with a power switch (fig. 28 ref. A) located below the lower safety guard (fig. 28 ref. B); to run it must be in
"I" position.
Once these operations have been carried out, the machine may be regulated using the remote control.
In order to transmit commands to the indoor unit, point the front of the remote control toward the unit's control panel.
The device emits a beep when it receives a command.
The maximum distance for transmission of commands is about 8 meters.
3.3.3 Turning the unit ON/OFF (button T1)
Use this button T1 to turn the system off (standby) or on.
Since the machine's control system has a memory, no setting will not be lost when it is turned off.
This button serves to switch the air conditioner on or off for brief periods of time.
In case of prolonged stop of the machine, it must be deactivated turning the main switch off or unplugging the machine
from the mains.
3.3.4 ECO key (button T2)
The energy saving function is activated through this button T2 and the switching on of the ECO icon remote control on the display,
which automatically optimizes machine running.
