Safety instructions:

The operations must be carried
out by electrical suitably trained in
hazardous area with knowledge of
increased safety explosion protection
IEC/EN 60079-14.
– The light fitting is not suitable for use in
hazardous areas of zone 0, 1 and
zone 20!
– The requirements of the IEC/EN 60079-31
regarding excessive dust deposits and
temperature to be considered from the user.
– The technical data indicated on the light
fitting are to be observed!
– Disconnect equipment before opening!
– Avoid powering up repeatedly for short
periods of time.
– Changes of the design and modifications to
the light fitting are not permitted!
– The light fitting shall be operated as
intended and in undamaged and perfect
condition!
– Only genuine Eaton's Crouse-Hinds
Business (Eaton) / CEAG spare parts may
be used for replacement!
– Repairs may only be carried out by Eaton/
CEAG or a qualified "electrician"!
– Do not keep these operating instructions
inside the light fitting during operation!
Observe the national safety rules and
regulations for prevention of accidents and
the following safety instructions which are
marked with an ( ) in these operating
instructions!
(1)
Intensive sun radiation in areas of high ambient
temperatures may cause inadmissible temperature
rise inside of the luminaire. This may result a
decrease in lifetime of the electronic ballast (EVG).
Therefore those luminaires should be switched off
during daytime by a photocell control.
(2)
The tests of clamping ranges and torque values
were performed with metal mandrel. The clamping
range can vary by using cables with different
manufacturing tolerances and material properties.
Please use the combination of sealing 1 + 2 + 3 for
the intermediate region.
(3)
When selecting the seal rubber, ensure that the cap
nut can be tightened when carrying out any future
maintenance work on the cable entry.
8
Explosion protected light fittings zone 2 and zone 21/22
Series: nLLK/S 08, nLLM 08
2.

Technical data

Light fittings with G13 bi-pin cap
nLLK/S 08 018/18
nLLK/S 08 018/18 (V-CG-S)
nLLK/S 08 036
nLLK/S 08 036/36 (V-CG-S)
nLLK/S 08 058
nLLK/S 08 058/58 (V-CG-S)
nLLM 08 018/18
nLLM 08 036/36
ATEX type examination certificate zone 2/22
Marking acc. to 2014/34/EU and standard: EN 60079-0
Zone 2
Zone 22
ATEX EC- type examination certificate zone 21
Marking accd. 2014/34/EU and standard: EN 60079-0
Zone 21
IECEx Certification of conformity zone 2/22
IECEx Category of application
Zone 2
Zone 22
IECEx Certification of conformity zone 21
IECEx Category of application
Zone 21
Rated voltage
ϕ
cos
Lamps to be fitted
Fluorescent lamps with G13 bi-pin cap to
18 W
36 W
58 W
Protection acc. to EN/IEC 60529
Insulation class to EN/IEC 61140
max. permissible ambient temperature
Storage temperature in original packing
Supply terminal clamping capacity per clamp
terminal (2.5 mm²)
Supply terminal clamping capacity
2 x per screw-terminal
min.
max.
Conductor cross-section with through-wiring
Cable entries
moulded plastics
suitable cables and test torques of the pressure
screw
seal 1+2+3
1 2
3
seal 1+2
1 2
3
seal 1
1 2
3
Test torque for screw in thread cable entry
metal thread
For permanently laid cables only
Test torque for breathing plug: M25 x 1.5
Dimensions of light fittings and for mounting
Lamp weight
nLLK/S 08 018/18
nLLK/S 08 036
nLLK/S 08 036/36
nLLK/S 08 058
nLLK/S 08 058/58
nLLM 08 018/18
nLLM 08 036/36
nLLK/S 08 018/18 V-CG-S
nLLK/S 08 036/36 V-CG-S
nLLK/S 08 058/58 V-CG-S
2 x 18 W
2 x 18 W
1 x 36 W
2 x 36 W
1 x 58 W
2 x 58 W
2 x 18 W
2 x 36 W
BVS 09 ATEX E 147
D II 3G__see table 1
D II 3D__see table 1
BVS 09 ATEX E 162
D II 2D__see table 1
IECEx BVS 11.0065
Ex nA ... see table 1 ... Gc
Ex tc ... see table 1 ... Dc
IECEx BVS 11.0069
Ex tb ... see table 1 ... Db
see table 1
0.98 cap.
IEC 60081-2220
IEC 60081-2420
IEC 60081-2122
IP 66
I
see table 1
1)
-25 °C to +55 °C
2 x 2.5 mm²
single-wire
1.5 mm
2
6.0 mm
2
2.5 mm for max. 16 A
2
M25 x 1.5
Ø cable
min. 8.0
(1)(2)
max. 10.0
min. 10.0
(1)(2)
max. 13.0
min. 13.5
(2)
max. 17,5
3.0 Nm
M20 x 1.5
3.0 Nm
see fig. 2
approx. 4.0 kg
approx. 6.0 kg
approx. 6.0 kg
approx. 7.3 kg
approx. 7.3 kg
approx. 6.6 kg
approx. 9.0 kg
approx. 5.0 kg
approx. 7.2 kg
approx. 8.7 kg
GB
multi-wire
1.5 mm
2
6.0 mm
2
Nm
1.5
2.0
2.3
2.6
1.3
2.3
