NOTE
If a warning tone (beep) sounds when pressing a button, this indicates that the
bed is operating on the backup battery - refer to the section "Backup battery"
on page 41.
NOTE
If a button is held down for more than 90 seconds, the function will be
automatically inhibited until the button is released. The function must then be
unlocked as described in the section "Function lockout" on page 40.
Patient
The patient controls are located on the inside panel of both
head end split side rails.
controls
Fig. 23 - Patient controls (patient's left hand side)
WARNING
The patient should be shown how to use these controls by the
caregiver.
Caregiver
The caregiver controls are located on the outside panel of both
controls head end split side rails.
Fig. 24 - Caregiver controls (patient's right hand side)
34
