B User interface description
B.2 User interface: dialog boxes

B.2.1 PID faceplate

B.2.1 PID faceplate
PID faceplate dialog box
Proportional-integral-derivative (PID) control is utilized to control all mixer modules as
well as most processes. Each PID faceplate contains the tuning parameters for an indi-
vidual PID control loop. Process PID settings can be adjusted by a user with appropriate
access rights.
PID faceplate dialog boxes can be accessed from the following locations:
•
•
by clicking the associated PID control loop overview displays.
Illustration of PID faceplate
dialog box
The illustration below shows an example of a PID faceplate dialog box.
1
2
3
4
376
Mixer0X window
or
PID Faceplates window
Xcellerex XDUO Quad Single-Use Mixeur Mode d'emploi 29-0885-07 AA
12
11
10
9
8
7
6
5
