B User interface description
B.1 User interface: windows
B.1.1 Mixer0X
Part
2
3
4
5
6
7
Clicking any of the text fields in the Batch Default PID Setpoints display opens the Default
PID Setpoints dialog box that shows an overview of all current batch setpoints.
352
Function
Selection buttons to move to different mixer states:
1 Start
2 Restart
3 Hold
4 Reset
5 Abort
Remarque :
Only valid transitions are enabled.
The fields to inform the user about the current batch state. The current
batch state is shown in green.
The length of time the batch has been in Running state, shown as
days:hours:minutes:seconds.
The length of time the batch has been in Held state, shown as
days:hours:minutes:seconds.
Double-arrow button to open or close the Batch Default PID Setpoints
part of the window (located below the button).
Batch Default PID Setpoints part of the window.
Xcellerex XDUO Quad Single-Use Mixeur Mode d'emploi 29-0885-07 AA
