1.1 Standard configurations

Tower configuration

Power module
(EX RT 7/11)

Rack configuration

Power module (EX RT 7/11)

1. Presentation

Dimensions in mm/
inches (H x W x D)
EX RT 7
444 x 131 x 635
EX RT 11
17.49" x 5.16" x 25"
EX RT EXB 7
EX RT EXB 11
Weight in kg/lbs
EX RT 7 22.5 / 49.6
EX RT 11 27.5 / 60.6
EX RT EXB 7 64.5 / 142
68.5 / 151
EX RT EXB 11
Battery module
(EX RT EXB 7/11)
Dimensions in mm/
inches (H x W x D)
EX RT 7
131 (3U) x 444 x 635
EX RT 11
5.16" (3U) x 17.49"
EX RT EXB 7
x 25"
EX RT EXB 11
Weight in kg/lbs
EX RT 7 22.5 / 49.6
EX RT 11 27.5 / 60.6
EX RT EXB 7 64.5 / 142
68.5 / 151
EX RT EXB 11
Battery module
(EX RT EXB 7/11)
