5. INSTALLATION
Before installation, please inspect the UPS. Ensure that no items inside the packaging were damaged
during transport. Do not turn on the device and immediately notify the carrier and retailer if there is
any damage or missing parts. Please keep the original packaging in a safe place for future use.
Packaging content
The box should contain the following:
Zen-X Master
Hardware installation guide
1. Your new UPS may be used immediately upon receipt. However, recharging the battery for at least
8 hours is recommended to ensure that the battery's maximum charge capacity is achieved.
Charge loss may occur during shipping and storage. To recharge the battery, simply leave the unit
plugged into an AC outlet.
2. With the UPS unit off and unplugged, connect the computer, monitor, and any externally powered
device etc. into the battery power supplied outlets. DO NOT plug a laser printer, copier, space
heater, vacuum, paper shredder or other large electrical device into the battery power supplied
outlets. The power demands of these devices will overload and possibly damage the unit.
3. Plug the UPS into a 2 pole, 3 wire grounded receptacle (wall outlet). Make sure the wall branch
outlet is protected by a fuse or circuit breaker and does not service equipment with large electrical
demands (e.g. air conditioner, refrigerator, copier, etc. DO NOT use extension cords or
multi-socket.
4. Press the power switch for 2 seconds to turn the unit on. The power on indicator light will illuminate
and the unit will "beep".
5. If an overload is detected, an audible alarm will sound and the unit will emit one long beep. To
correct this, turn the UPS off and unplug at least one piece of equipment from the battery power
supplied outlets. Wait 10 seconds. Make sure the circuit breaker is normal and then turns the UPS
on.
6. To maintain optimal battery charge, leave the UPS plugged into an AC outlet at all times.
7. To store your UPS for an extended period, cover it and store with the battery fully charged. Recharge
the battery every three months to ensure battery life.
26
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com Hot Line –
Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 12 24 AA 36 204 37
User
Wall screw x2
Manual
Wall anchors
x2
