Master-Slave (Eco) Function
Important
When you receive the Zen-X Master, the Eco (Master-Slave) function is enabled by default.
What is the Eco function?
This function manages devices connected to the so-called "Slave" outlets based on the
power supplied by the so-called "Master" outlet.
The Master outlet controls the power to two other "Slave" outlets: When electrical current is
•
detected on the Master outlet, the two Slave outlets are automatically powered.
The Slave outlets are powered only when a device plugged into the Master socket is turned
•
on, and vice versa. If the device plugged into the Master socket is off or consumes less than
30W, the Eco (Slave) sockets are automatically turned off within 3 minutes. Example: When
the computer is turned off, this allows the disconnection of the monitor and printer that are
plugged into the Slave sockets.
It helps manage energy more efficiently and prevents unused devices from consuming
electricity.
Disabling the Eco function
To disable or enable this function, press and hold the "Mute" button
and wait for 2 beeps.
Screen indication
When the "Master-Slave" function is enabled, the
•
When the "Master-Slave" function is disabled, the
•
When a device plugged into the Master outlet is turned off or consumed less than 30W, the
•
icon blinks for 3 minutes, then power to the Slave outlets is automatically cut off.
Silent mode
The silent mode can be activated or deactivated by pressing mute button twice in 3 seconds.
(Default: silent mode deactivated)
USB communication port
The USB connection allows communication between the computer and the UPS. To use this function,
simply download the "PowerMaster+" communication software (free) and its user manual from our
website in the "UPS/Software" section.
Protected and Backup Outlets
All outlets are surge-protected. Among them, six outlets provide backup power from the battery. This
means that in the event of a power outage, devices connected to the backed-up sockets can continue
to operate for several minutes.
24
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com Hot Line –
Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 12 24 AA 36 204 37
NS
icon appears on the screen.
NS
icon does not appear on the screen.
for 10 seconds
NS
