LCD screen
The LCD will display the UPS status including Input voltage, output voltage, percentage of load or
anomalies.
The LCD dimming can be set enable or disable by long pressing the mute button 20s. (Default: LCD
lighting activated)
Line Mode
Master-Slave enable:
NS
Slave on: fixed icon on
Slave off: flashing every second
Bat-mode
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com Hot Line –
Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 12 24 AA 36 204 37
Fault / Alarm
When the battery reaches a low discharge level, the silent mode is
disabled.
Bat mode: battery capacity
Line mode:
1.Battery charging: cycle lighting
2.Battery full charge: lighting
3.Line mode without charger: battery capacity
Battery Mode
Line mode:
Normal mode: fixed icon on
AVR mode: flashing every second
Load capacity
25
