Danfoss iC7 Guide D'installation page 69

iC7-Automation Frequency Converters
FA09–FA12, FK09a/FB09a, FK09c/FB09c, FK10a/FB10a
5
A
[mm (in)]
FA09 844 (33.2)
FA10
1051 (41.4)
FA11 1545 (60.8)
FA12 1545 (60.8)
FK09a/FB09a 944 (37.2)
FK09c/FB09c 1380 (54.3)
FK10a/FB10a 1176 (46.3)
5.1
A1
B1
FA09–FA10
FK09a/FB09a
FK09c/FB09c
FK10a/FB10a
A
A2
Danfoss A/S © 2025.05
A1 A2 B
25 (1.0) 20 (0.8) 180 (7.1)
25 (1.0) 20 (0.8) 280 (11.0)
17.6 (0.7) 15 (0.6) 412 (16.2)
17.6 (0.7) 15 (0.6) 508 (20.0)
25 (1.0) 24.2 (1.0) 180 (7.1)
25 (1.0) 18.7 (0.7) 180 (7.1)
25 (1.0) 24.5 (1.0) 280 (11.0)
B
B1
C1
C
B1 C C1
33.1 (1.3) 200 (7.9) 25 (1.0)
33.1 (1.3) 271 (10.7) 39.5 (1.6)
45.6 (1.8) 430 (16.9) 38.5 (1.5)
45.6 (1.8) 526 (20.7) 38.5 (1.5)
33.1 (1.3) 200 (7.9) 63.5 (2.5)
33.1 (1.3) 200 (7.9) 63.5 (2.5)
33.1 (1.3) 271 (10.7) 74.5 (2.9)
A1
B1
A
A2
D
225 (8.9) 4 x M10
225 (8.9) 4 x M10
225 (8.9) 6 x M10
225 (8.9) 6 x M10
225 (8.9) 4 x M10
225 (8.9) 4 x M10
225 (8.9) 4 x M10
B
B/2 B/2 B1
FA11–FA12
C/2 C/2 C1
C
AN45873927295002-000302 / 136R0272 | 69
