Information on refrigerant
▶ Observe pipe diameter and further specifications.
Pipe diameter [mm]
6.35 (1/4")
9.53 (3/8")
12.7 (1/2")
Table 48 Alternative pipe diameter
Specification of the pipes
Min. piping length for each indoor unit
Total pipe length
If the total pipe length ≤ 7.5 m × N
1)
If total pipe length ≥ 7.5 × N
Pipe thickness
Thickness of insulation against heat
Material of insulation against heat
1) Number of indoor unit connections
If 2 indoor units are connected and the total pipe length is 30 m with a 6.5 mm (1/
4'') piping diameter, the calculation should be as follows:
(30 m - 7,5 × 2) x 12 = 180gr (refrigerant to be added)
Table 49
3
Information on refrigerant
This device contains fluorinated greenhouse gases as refrigerant. The
device is hermetically sealed. You will find the information on the
refrigerant according to the Regulation (EU) No 517/2014 on
fluorinated greenhouse gases in the operating instructions of the device.
Information for the installer: If you refill refrigerant, enter the additional
charge size and the total charge size of the refrigerant in the table
"information on refrigerant" of the operating instructions.
4
Installation
4.1
Before installation
CAUTION
Risk of injury from sharp edges!
▶ Wear protective gloves during installation.
CAUTION
Danger of burns!
During operation the pipes become hot.
▶ Make sure, that the pipes cooled down before touching them.
▶ Check the scope of delivery for damage.
▶ Check whether a hissing sound due to negative pressure can be
detected when opening the pipes of the indoor unit.
30
Alternative pipe diameter [mm]
6
10
12
3 m
Additional refrigerant to
be added (liquid side):
1)
None
With Ø 6.35 mm (1/4"):
12 g/m
With Ø 9.53 mm (3/8"):
24 g/m
With Ø 9.53 mm (3/8"): ≥
0.8 mm
With Ø 15.9 mm (5/8"): ≥
1.0 mm
≥ 6 mm
Polyethylene foam
4.2
Requirements for installation site
▶ Observe minimum clearances ( Chapter 2.5 on page 29).
▶ Observe minimum room area.
Installation
height [m]
1.0
1.1
1.2
Minimum room area [m
0.6
9.0 10.5 12.5 14.5 17.0 19.5 22.0 25.0
1.8
1.0
1.5
1.5
2.2
1.0
1.0
1.0
Table 50 Minimum room area (1 of 3)
Installation
height [m]
1.8
1.9
2.0
Minimum room area [m
0.6
28.0 31.0 34.5 38.0 41.5 45.5 49.5 54.0
1.8
3.5
3.5
4.0
2.2
2.5
2.5
3.0
Table 51 Minimum room area (2 of 3)
Installation
height [m]
2.6
2.7
2.8
Minimum room area [m
0.6
58.0 63.0 67.5
1.8
6.5
7.0
7.5
2.2
4.5
5.0
5.0
Table 52 Minimum room area (3 of 3)
Notices regarding outdoor units
▶ The outdoor unit must not be exposed to machine oil vapour, hot
spring vapour, sulphur gas, etc.
▶ Do not install the outdoor unit directly next to water or where it is
exposed to sea air.
▶ The outdoor unit must always be kept free of snow.
▶ There must be no disruption caused by extract air or operating noise.
▶ Air should be able to circulate freely around the outdoor unit, but the
appliance must not be exposed to strong wind.
▶ Condensate that forms during operation must be able to drain off
easily. Lay a drain hose if required. In cold regions, installation of the
drain pipe is not advisable as freezing could result.
▶ Place the outdoor unit on a stable base.
General notices regarding indoor units
▶ Do not install the indoor unit in a room in which open ignition sources
(for example: open flames, an operating wall mounted gas boiler or
an operating electric heating system) are in operation.
▶ The installation location must not be higher than 2000 m above sea
level.
▶ Keep the air inlet and air outlet clear of any obstacles to allow the air
to circulate freely. Otherwise poor performance and higher noise
levels may occur.
▶ Keep TV, radio and and similar appliances at least 1 m away from the
unit and the remote control.
▶ Do not install the indoor unit in rooms with a high humidity (e.g.
bathrooms or utility rooms).
▶ Indoor units with a cooling capacity of 2.0 to 5.3 kW are designed for
a single room.
Notices regarding ceiling-mounted indoor units
▶ The ceiling construction and suspension system (on site) must be
able to support the weight of the appliance.
▶ Take minimum room area into account
Logacool AC ... MS – 6721852539 (2025/04)
Refrigerant [kg]
1.3
1.4
1.5
1.6
1.7
2
]
2.0
2.0
2.5
2.5
3.0
1.5
1.5
1.5
2.0
2.0
Refrigerant [kg]
2.1
2.2
2.3
2.4
2.5
2
]
4.5
5.0
5.0
5.5
6.0
3.0
3.5
3.5
4.0
4.0
Refrigerant [kg]
2
]
